A2 Cable Glands to BS6121

A2 Cable Glands

Features: This Cable Glands are suitable for unarmoured plastic or rubber sheathed cables for indoor as well as outdoor applications

Application: Suitable for all types of SWA Cable

Materials: High Quality Brass

IP Rating: IP 66

Standards: BS 6121

A2 Cable Glands Dimensions

ISO Metric Thread Entry Size
(mm)

Dimensions

Equivalent Imperial Thread Size Inches

Minimum Entry Thread Length 'D'
(mm)

Assembled Length excl. Thread Entry 'E'
(mm)

Hexagon Size

Bore 'A'

Across corners 'F'
(mm)

Min mm

Max mm

20/16

3.5

8.7

3/4S
10.0

23.0

24.5

20S

5.9

11.7

3/4S
10.0

21.8

26.5
20
6.4
14.0
3/4
10.0
23.0
30.0

25

10.0

20.0

1
10.0

25.0

40.5
32
19.0
26.3
1 1/4
10.0
30.0
46.0

40

25.0

32.2

1 1/2
15.0

31.5

56.0
50S
31.5
38.2
2S
15.0
27.5
61.5
50
36.5
44.1
2
15.0
31.5
67.0
63S
42.5
50.1
2 1/2S
15.0
30.0
78.5
63
49.5
56.0
2 1/2
15.0
31.5
83.5
75S
54.5
62.0
3S
15.0
29.5
89.0
75
60.5
68.0
3
15.0
32.5
94.5
90
66.0
79.4
3 1/2
15.0
49.5
121.0
*S denotes small cable entry size
